RMX-MOD150 RUGGED 1U SERVER

Categories , Tags , , Brand:

  • CPU: 2x INTEL E5 processor
  • SYSTEM MEMORY: Up to 1.5 TB DDR4
  • STORAGE: Up to 2 SATA SSD/HDD
Request a Quote

About

Features
Model: RMX-MOD150 RUGGED 1U SERVER
  • MIL-STD-810G Standard Qualified Rugged Computer
  • 1U Rack Mountable light weight aluminum construction
  • Dua Intel® Xeon® E5 v4 Broadwell Processor
  • 2 Hotswappable SSD with Thumblock and Keylock
  • Support Windows, Linux, VMWare OS

Specification

Specifications
CPU
Dual Intel® Xeon® Processor E5 v4 Broadwell Processors Up to 44 Cores 88 Threads
Chassis
1U Rackmount Cromate Coated Aluminium Construction. Grey, Black or Custom Color
System Memory
Up to 768GB RDIMM / 1,536GB LRDIMM ECC Memory 24 Memory Slots
Operating System
Windows 7/8/10/2012/2016, Ubuntu, Fedora, CentOS, Redhat, VMware
COM
1 x RS232
USB
Rear: 4 x USB 3.0 Front: 2 x USB 2.0
Ethernet
4 Gigabit RJ45 ports + 1 Management port Optional additional Gigabit/10G/RJ45/SFP+ ports
Display
1 VGA port
Remote Management
Remote Management port available
Air Filter
Optional Air Filter
Storage
2 or 3 Hotswappable 2.5" SSD/HDD Support RAID 0/1 + Hot spare option
Expansion
Optional 1 PCIe x16
MIL-STD-810G
-MIL-STD-810G Vibration -MIL-STD-810G Shock -MIL-STD-810G High Temperature -MIL-STD-810G Low Temperature
Battery
Button Lithium 3V/220 mAH
Power Requirements
Single AC 100V ~ 240V Power Supply Optional DC Power Supply
Hardware Monitoring
Yes
Operating Temperature
-10° ~ +50°C
Relative Humidity
5% ~ 95% relative humidity, non-condensing
Dimensions
1U (height) x 19" (width) x 500mm (depth)
Rackmout Kit
Standard Rail Kit or Custom Jonathan® rails
Weight
~ 7 Kg
