RMX-MOD145-D RUGGED 1U GPU SERVER
- CPU: INTEL Xeon
- SYSTEM MEMORY: Up to 128GB DDR4
- STORAGE: Up to 2 SATA SSD/HDD
- GPU: 1 Double Width GPU (Tesla P100, K80 K40, GRID M60, GTX 1080, Quadro M6000)
About
Features
Model: RMX-MOD145-D Rugged 1U GPU Server
- MIL-STD-810G Standard Qualified Rugged Computer
- 1 Double Width GPU (Tesla P100, K80 K40, GRID M60, GTX 1080, Quadro M6000)
- 1U Rack Mountable Server with Short Depth 455mm
- Intel® Xeon® Processor 16 Cores 32 Threads
- Hotswappable SSD / HDD with RAID
- Support Windows, Linux, VMWare OS
- Air Filter (Optional)
Specification
Specification
CPU
Single Intel® Xeon® Processor 16 Cores 32 Threads
Chassis
1U Rackmount heavy duty steel, stainless steel and aluminium, black color
System Memory
Up to 128GB DDR4 ECC RDIMM
Operating System
Windows 7/8/10/2012, Ubuntu, Fedora, CentOS, Redhat, VMware
USB
Rear: 2 x USB 3.0
Ethernet
2 10GbE SFP+, 2 GbE RJ45 ports. Optional 10GbE RJ45
Display
1 VGA port
Remote Management
Dedicated Remote Management port
Air Filter
Optional Air Filter
Storage
2x 2.5" SSD/HDD Hotswappable 2.5" SSD/HDD.
Support RAID 0/1/5/10
Optional 8x 2.5" SSD Hotswappable.
Optioanl DVD, Blu-ray
Expansion
1 Double Width PCIe 3.0 x16 for Full Height Full Length GPU Card
MIL-STD-810G
-MIL-STD-810G Vibration
-MIL-STD-810G Shock
-MIL-STD-810G High Temperature
-MIL-STD-810G Low Temperature
Battery
Button Lithium 3V/220 mAH
Power Requirements
Single AC 100V ~ 240V Power Supply
Optional DC Power Supply
Hardware Monitoring
Yes
Operating Temperature
-10° ~ +60°C
Relative Humidity
5% ~ 95% relative humidity, non-condensing
Dimensions
1U (height) x 19" (width) x 455mm (depth)
Weight
~ 8 Kg
